WIRE-BOND M A S O N R Y T O S T E E L C O L U M N S

Channel Slots Channel Slot
Anchor ( corrugated )
Designed to anchor masonry to structural
steel columns or beams. Dimensions are 12 gauge or 16 gauge x 1-1/4″
12gauge thick x 1-3/4” wide. wide 3-1/2″, 4-1/2″ and 5-1/2″
standard lengths.
Custom sizes available

#1301

126” #1401
#1302
8”

mill galvanized,
hot dip galvanized
or stainless steel

Channel Slot Anchor
12 gauge or 16 gauge x 1-
1/4″wide x various lengths. #2800

Notched Column Anchors #2801

Dimensions are 12 gauge thick x 2″
#1402
wide x 7″ long with 2″ bend. Flange
slot is 5/8″ wide x 1″ deep, located 1″
from end, custom sizes are available.
Finishes: Mill Galvanized, Hot Dip
Galvanized and Stainless Steel

Column Flange Ties

For tying masonry to steel columns. Constructed of steel wire
meeting requirements of ASTM A1064/A1064M. Available in 2.5”
2.5”
3/16” or 1/4” wire. Finishes: mill galvanized, hot dip galvanized,
App .5” and stainless steel. App .5”

10” - 12”
14” - 16”
#2601
3” - 5” #2600
7” - 9”

2.5”
2.5”
